EMS200S24DC 200W Dimmable Outdoor Stainless Steel 24VDC Transformer

EMS200S24DC 200W Dimmable Outdoor Stainless Steel 24VDC Transformer

The EMS200S24DC is a 200W outdoor magnetic transformer designed to provide 24VDC power for compatible low-voltage lighting systems. It uses a stainless steel outdoor enclosure for durable power distribution in landscape and architectural lighting applications.

Why Choose the EMS200S24DC?

✔ 200W Capacity
Provides up to 200W of power for compatible low-voltage lighting loads.

✔ 24VDC Output
Designed around a 24VDC output configuration.

✔ Phase-cut dimmable
Manufacturer specifications identify this model as phase-cut dimmable for compatible dimming applications.

✔ Outdoor NEMA 3R Enclosure
Stainless steel, NEMA 3R construction is intended for outdoor transformer installations.

Electrical Specifications

• Model: EMS200S24DC
• Input Voltage: 120V 60Hz
• Output Configuration: 24VDC
• Output Voltage - No Load: 25.8VDC
• Output Voltage - Fully Loaded: 23.5VDC
• Maximum Wattage: 200W
• Maximum Output Current: 8.3A
• Efficiency: 87%
• Circuit Configuration: Single circuit
• Dimming: Phase-cut dimmable

Construction & Certification

• Enclosure: Stainless steel, NEMA 3R
• Certification: UL 2108 / CSA C22.2 No. 250.0
• Dimensions: 8 x 4.15 x 3.41 in

How to Select the 200W 24VDC stainless steel transformer

Choose the EMS200S24DC when a project requires a 200W 24VDC stainless steel transformer and the available supply matches 120V 60Hz. Confirm that every connected fixture accepts 24VDC and that the planned load fits the transformer’s circuit configuration. Its stainless steel NEMA 3R enclosure is intended for outdoor transformer installations.

This is a single-circuit model, so all connected fixture wattage counts toward the listed 200W maximum. The specifications show 25.8VDC at no load and 23.5VDC at full load, giving installers a reference for expected output as the connected load changes. Final transformer location, wiring, circuit protection and code compliance should be reviewed by a qualified installer before the system is energized.

Frequently Asked Questions

What lighting systems can use the EMS200S24DC?
This 200W 24VDC stainless steel transformer is intended for compatible low-voltage landscape or architectural lighting that accepts 24VDC power. The connected load must stay within the listed 200W capacity and 8.3A output-current limit.

Is the EMS200S24DC dimmable?
Yes. The product data lists Phase-cut dimmable. The wall control, transformer and connected fixtures must all be compatible with that dimming method.

Can this transformer be installed outdoors?
Yes. Its stainless steel NEMA 3R enclosure is specified for outdoor transformer installations. Final placement and wiring must still follow the product instructions and applicable electrical requirements.

Compare voltage, capacity, circuit and enclosure options in our low-voltage landscape lighting transformer collection.

Official EMCOD Specification Sheet: Download PDF
