ESL75W 75W Outdoor Stainless Steel 12/15VAC Landscape Transformer

ESL75W 75W Outdoor Stainless Steel 12/15VAC Landscape Transformer

The ESL75W is a 75W outdoor magnetic transformer designed to provide 12/15VAC multi-tap power for compatible low-voltage lighting systems. It uses a stainless steel outdoor enclosure for durable power distribution in landscape and architectural lighting applications.

Why Choose the ESL75W?

✔ 75W Capacity
Provides up to 75W of power for compatible low-voltage lighting loads.

✔ 12/15VAC multi-tap Output
Designed around a 12/15VAC multi-tap output configuration.

✔ Non-dimmable
Manufacturer specifications identify this model as non-dimmable for compatible dimming applications.

✔ Outdoor NEMA 3R Enclosure
Stainless steel, NEMA 3R construction is intended for outdoor transformer installations.

Electrical Specifications

• Model: ESL75W
• Input Voltage: 120V 60Hz
• Output Configuration: 12/15VAC multi-tap
• Output Voltage - No Load: 12 / 15VAC
• Output Voltage - Fully Loaded: 11.5 / 14.5VAC
• Maximum Wattage: 75W
• Maximum Output Current: 6.2 / 5A
• Efficiency: 90%
• Circuit Configuration: Single circuit
• Dimming: Non-dimmable

Construction & Certification

• Enclosure: Stainless steel, NEMA 3R
• Certification: UL 1838 / CSA C22.2 No. 250.0, 250.7
• Dimensions: 8.5 x 3.75 x 4.4 in

How to Select the 75W 12/15VAC multi-tap landscape lighting transformer

Choose the ESL75W when a project requires a 75W 12/15VAC multi-tap landscape lighting transformer and the available supply matches 120V 60Hz. Confirm that every connected fixture accepts 12/15VAC multi-tap and that the planned load fits the transformer’s circuit configuration. Its stainless steel NEMA 3R enclosure is intended for outdoor transformer installations.

This is a single-circuit model, so all connected fixture wattage counts toward the listed 75W maximum. The specifications show 12 / 15VAC at no load and 11.5 / 14.5VAC at full load, giving installers a reference for expected output as the connected load changes. Final transformer location, wiring, circuit protection and code compliance should be reviewed by a qualified installer before the system is energized.

Frequently Asked Questions

What lighting systems can use the ESL75W?
This 75W 12/15VAC multi-tap landscape lighting transformer is intended for compatible low-voltage landscape or architectural lighting that accepts 12/15VAC multi-tap power. The connected load must stay within the listed 75W capacity and 6.2 / 5A output-current limit.

Is the ESL75W dimmable?
No. The product data lists the ESL75W as non-dimmable, so it should be used with compatible non-dimming lighting loads.

Can this transformer be installed outdoors?
Yes. Its stainless steel NEMA 3R enclosure is specified for outdoor transformer installations. Final placement and wiring must still follow the product instructions and applicable electrical requirements.
