LT2404A Die Cast Aluminum Standard G4 Path Light

12V Die Cast Aluminum Standard G4 Path Light – LT2404A

The LT2404A Die Cast Aluminum Standard G4 Path Light is designed for low voltage landscape lighting applications. Built with durable die cast aluminum construction and paired with a frosted or clear cylindrical glass lens, it provides dependable pathway and area illumination in residential and commercial outdoor settings.

Its clean profile, weather-resistant design, and flexible G4 compatibility make it a practical solution for landscape lighting systems requiring reliable long-term performance.

Why Choose the LT2404A Path Light?

✔ Durable Die Cast Aluminum Construction
Hat and stem are made from heavy-duty die cast aluminum for strength and outdoor durability.

✔ G4 Bi-Pin Compatible
Designed for G4 lamps, allowing adjustable lumen output and color temperature based on the selected bulb.

✔ Weather-Resistant Design
IP65 rating ensures reliable performance in wet and harsh outdoor environments.

✔ Flexible Lens Options
Available with frosted glass for softer diffusion or clear glass for brighter light output.

✔ Prewired for Installation
Includes 48″ (1.2m) 18AWG SPT-1W lead wire and a standard 8.5″ large ground stake.

✔ Classic Finish Options
Offered in ORB and Matte Black to complement a wide range of landscape designs.

Technical Specifications – LT2404A

Model: LT2404A
Construction: Die Cast Aluminum (Hat and Stem)
Finish Options: ORB / Matte Black
Lens Options: Frosted or Clear Cylindrical Glass
Socket Type: Fixed GU5.3 Bi-Pin Socket
Lamp Type: G4 (Sold Separately)
Input Voltage: 9–17V AC/DC
Lead Wire: 48″ (1.2 meters) SPT-1W, 18AWG
Mounting: Standard 8.5″ Large Ground Stake (Included)
IP Rating: IP65
Certification: ETL
Working Temperature: -45°C to 45°C
Output Lumens: According to G4 Lamp
Beam Spread: According to G4 Lamp
Color Temperature (CCT): According to G4 Lamp
Color Rendering Index (CRI): According to G4 Lamp
Power Supply: LT Tech Low Voltage Transformer (Sold Separately)

Dimensions & Packaging

Package Size: 24.02″ × 7.32″ × 3.35″
Gross Weight: 1.63 lbs

Warranty

Warranty: 5 Years
Structure: Lifetime

Ideal Applications

• Pathway lighting
• Garden and landscape beds
• Driveway borders
• Outdoor seating areas
• Residential and commercial landscape lighting systems

Lumen output, beam spread, CCT, and CRI depend on the selected G4 lamp.
